Clevo M-series M520N, Laptop Motherboard Schematic diagram

Click on picture to enlarge	Price: US $15.00 Major components: CPU : Intel Yonah / Merom Chipset :Intel Calistoga 945GM / ICH7-M Video: UMA KBC(Embeded Controller),SIO : H8S-2111 Known motherboard part numbers : 6-71-M52N0-D01 File type : PDF Language : English

Click on picture to enlarge

Price: US $15.00

Major components:

CPU : Intel Yonah / Merom
Chipset :Intel Calistoga 945GM / ICH7-M
Video: UMA
KBC(Embeded Controller),SIO : H8S-2111

Known motherboard part numbers :

6-71-M52N0-D01

File type : PDF
Language : English

Updated: 12-07-2010
