Gateway M600 Series M675PRR, Laptop Motherboard Schematic diagram
|
|
Price: US $11.25 CPU :Intel Northwood/PRESCOTT Thermal Sensor :MAX6648MUA(CPU) + LM90(VGA) Chipset :Intel SPRINGDALE-PE / ICH5 Video :ATI M11-P Clock Generator :CK-409 Audio Codec :Sigmatel ST9758 Audio Amplifier :LM4866MTE KBC(Embeded Controller),SIO :PC87591, PC87391 LAN Controller :KENAI II / KINNERETH-R Card BUS,IEEE 1394, etc... :PCI4510 <Power System> OZ862AS ISL6207CB-T ISL6207CB-T ISL6207CB-T ISL6207CB-T ISL6247 LP2996 LP2996 SC1565 SC1470 MAX1714AEEP MAX1632 Total Pages : 45 File type : PDF Language : English |
|---|
