Apple MLB 820-01774 + 820-01969, Logic Board / Motherboard BoardView file and Schematic diagram

Click on picture to enlarge	Price: US $22.50 iPhone 12 mini - MG633LL/A* - iPhone13,1 - A2176* - 3539* iPhone 12 mini - MGAP3VC/A* - iPhone13,1 - A2398* - 3540* iPhone 12 mini - MGE13B/A* - iPhone13,1 - A2399* - 3541* iPhone 12 mini - MG823CH/A* - iPhone13,1 - A2400* - 3541* What's included : — Schematic Diagram — BoardView file and BoardView Software — Component explain Main components: CPU : 3.0 GHz Apple A14 Bionic Screen: 5.4" Super Retina XDR Year: 2020 File types : Schematic Diagram: PDF BoardView file : PCB Silkscreen: N/A

Click on picture to enlarge

Price: US $22.50

iPhone 12 mini - MG633LL/A* - iPhone13,1 - A2176* - 3539*
iPhone 12 mini - MGAP3VC/A* - iPhone13,1 - A2398* - 3540*
iPhone 12 mini - MGE13B/A* - iPhone13,1 - A2399* - 3541*
iPhone 12 mini - MG823CH/A* - iPhone13,1 - A2400* - 3541*

What's included :

— Schematic Diagram
— BoardView file and BoardView Software
— Component explain

Main components:

CPU : 3.0 GHz Apple A14 Bionic
Screen: 5.4" Super Retina XDR
Year: 2020

File types :

Schematic Diagram: PDF
BoardView file : PCB
Silkscreen: N/A

Updated: 01-12-2025
