Wistron OEM Antman14N AMD UMA 213084-1 213084-SC N0NCY$LA 455.0QD01.A001 + Antman N UMA IO BD 213528-1 FC30W$JA, Motherboard BoardView files, I/O Board and motherboard Schematic diagram
|
|
Price: US $25.00 — Schematic Diagram for MB — Schematic Diagram for DB — 2 BoardView files for MB (GR and PCB) + BoardView Software — Power UP Sequence Diagram — Power Sequence Stop-by-Step Diagram — Power Block Diagram — Type-C Adapter sequence Type-C ADP IN without Barrel ADP (DC mode) Type-C ADP OUT without Barrel ADP (DC mode) Type-C ADP IN after Barrel ADP IN Type-C ADP IN without battery (Dead Battery) Type-C ADP OUT after Barrel ADP IN — Thermal Block Diagram — Audio Block Diagram — CLK Block Diagram Major components: CPU/RAM: AMD Barcelo + DDR4 GPU : UMA or DIS (GN18-S5) + GDDR6 EC : NPCE48AL File types : Schematic Diagram for MB: PDF / Searchable Schematic Diagram for I/O : PDF / Searchable BoardView file : GR & PCB (FlexBV) Language : English |
|---|
