LCFC OEM NM-E812 KX3B0/KX3D1 + (NS-D363 HX3B0), Motherboard Schematic diagram

Click on picture to enlarge	Price: US $20.00 Motherboard p/n: KX3B0/KX3D1 NM-E812 DMIC Board p/n: HX3B0 NS-D363 What's included: — 2 Schematic Diagrams for Motherboard and DMIC Board — Power Block Diagram (Power Distribution Diagram) — Hardware Maintenance Manual — BIOS file* Main Components: CPU/HUB/RAM: Intel Raptor Lake-U/P / LPDDR5 (LPDDR5X) GPU/VRAM : UMA EC : MEC1724 File Types: Schematic Diagram(s) : PDF / Searchable Silkscreen : N/A BoardView file(s) : N/A HMM : PDF / Searchable BIOS files* : .FL1, .FL2 (Original file from the official Lenovo website) Language : English * The BIOS files are offered AS-IS

Click on picture to enlarge

Price: US $20.00

Motherboard p/n: KX3B0/KX3D1 NM-E812
DMIC Board p/n: HX3B0 NS-D363

What's included:

— 2 Schematic Diagrams for Motherboard and DMIC Board
— Power Block Diagram (Power Distribution Diagram)
— Hardware Maintenance Manual
— BIOS file*

Main Components:

CPU/HUB/RAM: Intel Raptor Lake-U/P / LPDDR5 (LPDDR5X)
GPU/VRAM : UMA
EC : MEC1724

File Types:

Schematic Diagram(s) : PDF / Searchable
Silkscreen : N/A
BoardView file(s) : N/A
HMM : PDF / Searchable
BIOS files* : .FL1, .FL2 (Original file from the official Lenovo website)
Language : English

* The BIOS files are offered AS-IS

Updated: 22-08-2023
