Acer Aspire A315-53, Motherboard BoardView file and Schematic diagram
Click on picture to enlarge |
What's included: — 4 Scheamtic Diagrams for Motherboard, Hall Sensor, I/O and ODD boards — 2 BoardView files for Motherboard* and Hall Sensor Board + BoardView Software — Power sequence timing diagram — Power distribution diagram — SMBUS Routing Table — Schematic diagrams for Hall Sensor and ODD boards — BoardView file for Hall Sensor Board Major components: CPU: Intel KabyLake-U/R (U22/U42) + DDR4 GPU: UMA EC: KB9022 File types - Schematic Diagram(s) : PDF (Searchable) BoardView file(s) : .BDV (Honhan) Language : English * BoardView file for MB is taken from an identical MB with DIS GPU. Some components shown on the 4th picture in red frames are not shown on the BoardView. |
---|
