Asus C90-series C90S, Laptop Motherboard Schematic diagram

Click on picture to enlarge	Price: US $17.25 Included : Power Flow Diagram Power Sequence Diagram Power Board Schematic diagram **"Board view" files for motherboard,VGA Card, Inverter,Power Board + software(viewer). Using this tool you will be able to find any component,pin or signal on your motherboard in a few seconds! Major components CPU :Intel Conroe / Conroe-L Chipset :Intel 945 // ICH7 Video: MXM VGA Card KBC(EC),SIO : ITE IT8511E File type : PDF Language : English

Click on picture to enlarge

Price: US $17.25

Included :

*Power Flow Diagram
**Power Sequence Diagram
***Power Board Schematic diagram
****"Board view" files for motherboard,VGA Card, Inverter,Power Board
+ software(viewer). Using this tool you will be able to find any
component,pin or signal on your motherboard in a few seconds!

Major components

CPU :Intel Conroe / Conroe-L
Chipset :Intel 945 // ICH7
Video: MXM VGA Card
KBC(EC),SIO : ITE IT8511E

File type : PDF
Language : English

Updated: 01-10-2010
