Xiaomi Mi Series Mi 10 Pro (Mi10 Pro), motherboard Schematic diagram

Click on picture to enlarge

Price: US $20.00

This is a set of documents (files) for Xioami Mi 10 Pro (Mi10 Pro), namely:

— Motherboard Schematic Diagram
— Motherboard Component Placement Diagram
— Component Distribution Map


CPU : Qualcomm Snapdragon 855 SM8150
Known Logic Board p/n: 35100J1M0A, 52M00J2P2000, 35100J2M0A, 52100J240000





File type : PDF
(Schematic diagrams and Component Placement Diagrams are Searchable PDF files (unless otherwise specified in the description above))
Language : English (unless otherwise specified in the description above)
