Xiaomi Mi Series Mi 5S Plus (Mi5s plus), motherboard Schematic diagram

Click on picture to enlarge	Price: US $15.00 This is a set of documents (files) for Xiaomi Mi 5S Plus (Mi5s plus), namely: — System Block Diagram — Logic Board Schematic Diagram — Functional Block Diagrams — Component Placement Diagram — Component Distribution Map — Level I & II Maintenance Manual (Chinese language only) CPU : Qualcomm Snapdragon 821 MSM8996 Pro Known Logic Board p/n: 52B0700P3F00, 3501B07P3D0 File type : PDF (Schematic diagrams and Component Placement Diagrams are Searchable PDF files (unless otherwise specified in the description above)) Language : English (unless otherwise specified in the description above) Ad: Special Offer! All available at this moment Schematic diagrams, Сomponent placement diagrams (BoardView files) and Repair Guides for Xiaomi products. Please click on the link below. (it's working) Xiaomi Special Offer File not found

Click on picture to enlarge

Price: US $15.00

This is a set of documents (files) for Xiaomi Mi 5S Plus (Mi5s plus), namely:

— System Block Diagram
— Logic Board Schematic Diagram
— Functional Block Diagrams
— Component Placement Diagram
— Component Distribution Map
— Level I & II Maintenance Manual (Chinese language only)

CPU : Qualcomm Snapdragon 821 MSM8996 Pro
Known Logic Board p/n: 52B0700P3F00, 3501B07P3D0

File type : PDF
(Schematic diagrams and Component Placement Diagrams are Searchable PDF files (unless otherwise specified in the description above))
Language : English (unless otherwise specified in the description above)
